Merida BIG.TRAIL 600 2021

MTB Trail
Groupset
Shimano Deore
Frame material
Alloy
Wheel size
29"
Suspension type
Hardtail
Weight
13,64 kg
Front travel
140mm
Merida BIG.TRAIL 600 2021

About the Merida BIG.TRAIL 600 2021

The Merida BIG.TRAIL 600 2021 is a Hardtail Trail Mountain Bike with a alloy frame. Equipped with a Shimano Deore drivetrain of 12 gears (1x12). Its features include internal routing, dropper seatpost, and hydraulic disc brakes. The bike weighs approximately 13,64 kg.

Features

The Merida BIG.TRAIL 600 2021 has 4 features listed below.
cabeamento-interno
Internal routing More info
canote-retratil
Dropper seatpost More info
freio-hidraulico
Hydraulic disc brakes More info
tubeless-ready
Tubeless ready More info

Specifications

Components
Saddle
Merida COMP CC
Headset
Merida M2331
Seatpost
Merida COMP TR 30.9mm
Brakes
Shimano BR-MT410 Hydraulic disc brake 2 piston
Brake hose color kit
Black
Brake hose kit
SM-BH59-JK-SS
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Black (SHIMANO logo)
Hose joint
Straight
J-Kit spec for OEM
Model
BR-MT410
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad standard
B03S Resin
Piston
2
Piston material
Resin
Recommended disc brake rotor
SM-RT30*
SM-RT54*
SM-RT56*
Handlebar
Merida EXPERT TR aluminium
Discs
Shimano SM-RT10
Adapter finish
Painted
Adapter material
Steel
Lock ring internal external type material
Steel
Model
SM-RT10
Rotor finish
Polished
Rotor material
Stainless steel
Drivetrain
Shifter
Shimano Deore SL-M6100 RAPIDFIRE PLUS
Base cover material
GFRP
Clamp bolt material
Stainless steel
Primary color
Series color
Compatible rear derailleur type
MTB 12-speed
Compatible with I spec
Main lever body material
GFRP & Steel
Max multiple shifts main lever rear
3
Model
SL-M6100-R
Mount type
Clamp band
Optical gear display
With
Speeds
12
Release function
2-WAY RELEASE
release_lever_body.material
GFRP & Steel
Shifter type
RAPIDFIRE PLUS
Shifting lever bracket finish
Painted
Shifting lever bracket material
Aluminum
Shifting lever cable finish
OPTISLICK
Shifting lever cable material
Stainless steel
Shifting lever cable adjust
Crankset
Race Face Ride
Cassette
Shimano Deore CS-M6100-12 HYPERGLIDE+
Aluminum spider arm finish
Painted
Aluminum spider arm pieces
1
Combination names
10-51T
Compatible chain
HG 12-speed
Lock ring finish
Plated
Lock ring material
Steel
Model
CS-M6100-12
Steel gear finish
Plated
Steel gear pieces
12
Type
HYPERGLIDE+
Rear derailleur
Shimano Deore RD-M6100 SGS 12s
B axle hollow
B axle material
Stainless steel
Bracket body finish
Painted
Bracket body material
Aluminum
Compatible chain
HG 12-speed
Lower pulley max
51T
Lower pulley min
51T
Model
RD-M6100-SGS
P axle material
Steel
pulley.screws_material
Stainless steel
pulley.sunken_type_pulley_screw
Pulley teeth
13T
Pulley cage
SGS
Speeds
12
Upper pulley max
10T
Upper pulley min
10T
Total capacity
41T
Chain
KMC X12
Bottom bracket
Race Face PF30
Frameset
Front suspension
Marzocchi Z2 Air
Frame
Merida BIG.TRAIL TFS, aluminium
Wheels
Tires
Maxxis Dissector
Rims
Merida EXPERT TR 29mm aluminium
Rear hub
Merida EXPERT TR
Front hub
Merida EXPERT TR

Geometry

Size SM MD LG XL
a
Seat tube length
380,0
410,0
430,0
450,0
b
Seat tube angle
75,5º
75,5º
75,5º
75,5º
c
Top tube length
576,0
597,0
619,0
642,0
d
Head tube length
95,0
100,0
110,0
120,0
e
Head tube angle
65,5º
65,5º
65,5º
65,5º
f
Rake
41,0
41,0
41,0
41,0
g
Trail
126,0
126,0
126,0
126,0
h
Wheelbase
1147,0
1169,0
1193,0
1217,0
i
Chainstay length
432,0
432,0
432,0
432,0
j
Bottom bracket drop
66,5
66,5
66,5
66,5
k
Stack height
633,0
638,0
647,0
656,0
l
Reach
412,0
432,0
452,0
472,0
m
Standover height
713,0
720,0
722,0
725,0
x
Bottom bracket height
308,0
308,0
308,0
308,0
y
Front center
723,0
745,0
769,0
793,0
