Specialized Chisel Comp 2020

MTB Cross Country
2020 / 2021
Groupset
SRAM SX Eagle
Frame material
Alloy
Wheel size
29"
Suspension type
Hardtail
Front travel
100mm
Specialized Chisel Comp 2020

About the Specialized Chisel Comp 2020

The Specialized Chisel Comp 2020 is a Hardtail Cross Country Mountain Bike with a alloy frame. Equipped with a SRAM SX Eagle drivetrain of 12 gears (1x12). Its features include internal routing, boost 110 , and boost 148.

Features

The Specialized Chisel Comp 2020 has 4 features listed below.
cabeamento-interno
Internal routing More info
cubo-dianteiro-boost
Boost 110 More info
cubo-traseiro-boost
Boost 148 More info
freio-hidraulico
Hydraulic disc brakes More info

Specifications

Acessories
Grip
Specialized Trail Grips
Components
Handlebar
Specialized Mini Rise Alumínio
Seatpost
Specialized Alumínio, 30.9mm
Steam
Specialized XC
Brakes
Shimano BR-MT500 Hydraulic disc brake 2 piston
Brake hose color kit
Black
Brake hose kit
SM-BH59-JK-SS
Brake type
Hydraulic disc brake
Caliper finish
Painted
Caliper material
Aluminum
Caliper fixing bolt anti loosen method
Snap ring
Caliper fixing bolt material
Steel
Caliper fixing bolt tool size
5 mm
Primary color
Black
Hose joint
Straight
J-Kit spec for OEM
Model
BR-MT500
Mount type
Post-type
Oil
SHIMANO Mineral
One way bleeding
Pad standard
B03S Resin
Pad mount
Split pin (stainless steel)
Piston
2
Piston material
Resin
Recommended disc brake rotor
SM-RT54*
SM-RT56*
Drivetrain
Bottom bracket
SRAM Power Spline
Shifter
SRAM SX Eagle Trigger 12s
Cable length
2200mm
Cable pull ratio
X-actuation
Color
Black
Compatible derailleur hub
RD:12s
Matchmaker compatible
No
Model
SL-SX-1-A1
Name
SX Eagle Trigger Shifter
Shifter type
Trigger
Speeds
12
Chain
SRAM SX Eagle
Cassette
SRAM PG-1210 Eagle 12s
Cog finish cassete
Black
Cog sizes
11-50t:11,13,15,17,19,22,25,28,32,36,42,50
Gearing
11-50t
Model
CS-PG-1210-A1
Name
PG-1210 Eagle™ Cassette
Speed
12s
Technology cassete
PG
Rear derailleur
SRAM SX Eagle 12s
Cable pull ratio
X-actuation
Cage
Long
Cage material
Steel
Color
Black
Max tooth
50
Model
RD-SX-1-A1
Name
SX Eagle Rear Derailleur
Pulley bearings material
Steel
Speed
12s
Crankset
SRAM SX Eagle 11, 11/12s
BB compatibility
All SRAM MTB WIDE DUB BBs
DUB BSA73
DUB PF89.5
DUB PF92
DUB PF30 MTB73
DUB BB30 MTB73
DUB:BSA73
PF89.5
PF92
PF30 MTB73
BB30 MTB73
BSA MTB68SP
PowerSpline BB
BB spindle interface
DUB, Power Spline
Bolt circle diameter bcd
Direct Mount (DM)
Chain line
49.0mm, 52.0mm, 55.0mm
Chainring material
Steel
Chainring size
28T, 30T, 32T, 34T
Crank arm length
155mm, 165mm, 170mm, 175mm
Model
FC-SX-1-A1
Name
SX Eagle™ Crankset
Speeds
11, 11/12
Frameset
Front suspension
RockShox Judy Gold Solo Air
Color
Diffusion Black, Gloss Black
Damper type
Motion Control
fork offset
40mm (26"), 42mm (27.5"), 46mm (29"), 51mm (27.5"), 51mm (29")
Max tire width (mm)
58, 62, 81
Maximum rotor size
185mm, 210mm
Minimum rotor size
160mm
Model
FS-JDYG-RL-A3
Name
Judy Gold RL
Spring
Solo Air
Travel (mm)
100mm, 120mm, 80mm
Upper tube type
30mm straight wall aluminum
Wheel size
26", 27.5", 29"
Frame
Specialized M5 Alumínio
Wheels
Rims
Specialized Stout XC 29
Front hub
Specialized selado, 15x110mm, spacing, 28h
Tires
Specialized Fast Trak 29x2.3"
Rear hub
Specialized sealed, 12x148mm, thru-axle, 32h

Geometry

Size XS SM MD LG XL
a
Seat tube length
370,0
400,0
430,0
470,0
520,0
b
Seat tube angle
74,0º
74,0º
74,0º
74,0º
74,0º
c
Top tube length
552,0
571,0
598,0
626,0
652,0
d
Head tube length
95,0
95,0
95,0
110,0
125,0
e
Head tube angle
69,8º
69,8º
69,8º
69,8º
69,8º
f
Rake
51,0
51,0
51,0
51,0
51,0
g
Trail
82,0
82,0
82,0
82,0
82,0
h
Wheelbase
1059,0
1077,0
1104,0
1132,0
1158,0
i
Chainstay length
434,0
434,0
434,0
434,0
434,0
j
Bottom bracket drop
57,5
57,5
57,5
57,5
57,5
k
Stack height
590,0
599,0
609,0
623,0
637,0
l
Reach
384,0
399,0
422,0
445,0
466,0
m
Standover height
735,0
764,0
794,0
818,0
849,0
x
Bottom bracket height
312,5
312,5
312,5
312,5
312,5
y
Front center
631,0
650,0
676,0
704,0
730,0
